- The largest device support in the industry: Supports 73,295 IC
devices from 272 manufacturers and continuing.
- Two programmers in one, a double value: PC mode for engineering and Stand-alone mode for production. The programmer operates in either PC hosted mode or stand-alone mode.
- Programs up to 256 GB size NAND Flash Devices
- Ultra-Fast Programming Speed: Programs 15%-30% faster than SuperPro 5000 series programmers
- Built-in 144 universal pin drivers.
- A CF (compact flash) card stores the project files.
- CE and RoHS Compliant.
- The largest device support in the industry: Supports 73,295 IC
devices from 272 manufacturers and continuing.
- Two programmers in one, a double value: PC mode for engineering and Stand-alone mode for production. The programmer operates in either PC hosted mode or stand-alone mode.
- A CF (compact flash) card stores the project files.
- Ultra-Fast Programming Speed: Programs and verifies 64 Mb NOR Flash memory in 11.3 seconds and 1 GB NAND Flash in 108 seconds.
- Built-in 144 universal pin drivers.
- CE and RoHS Compliant.
- Large device support: Supports 64,096 IC devices from 254 manufacturers and
continuing.
- Two programmers in one, a double value: PC mode for engineering and Stand-alone mode for production. The programmer operates in either PC hosted mode or stand-alone mode.
- Ultra-Fast Programming Speed: Programs and verifies 64 Mb NOR Flash memory in
11.3 seconds.
- Built-in 144 universal pin drivers
- A CF (compact flash) card stores the project files.
- CE and RoHS Compliant.
- Fastest lowest cost Stand-Alone Programmer: With ARM7 MCU it gives ultra-fast
programming experience.
- Supports 35,030 IC
devices from 217 manufacturers and continuing
- Two programmers in one, a double value: PC mode for engineering and
Stand-alone mode for production. The programmer operates in either PC hosted
mode or stand-alone mode.
- A CF (compact flash) card stores the project files.
- Built-in 48 universal pin drivers.
- CE and ROHS Compliant.
- Fastest lowest cost Programmer: With ARM7 MCU it gives ultra-fast programming
experience.
- Supports 28,569 IC
devices from 211 manufacturers and continuing
- Programs devices with Vcc as low as 1.2V.
- Built-in 48 universal pin drivers.
- CE and ROHS Compliant.
- Fastest lowest cost Programmer: With ARM7 MCU it gives ultra-fast programming experience.
- Supports around 20,000 devices and priced ad only $595
- Programs devices with Vcc as low as 1.2V.
- Built-in 48 universal pin drivers.
- CE and ROHS Compliant.
- The largest device support in the industry: Supports 73,295 IC devices from 272 manufacturers and continuing
- Ultra-Fast Programming Speed: Programs and verifies 64 Mb NOR Flash memory in
11.3 seconds and 1 GB NAND Flash in 108 seconds.
- Concurrent & independent
modules: 4 independent programming modules operating concurrently for high speed
programming.
- Built-in 144 universal pin drivers
- CE and ROHS Compliant.
- Large device support: Supports 64,096 IC devices from 254 manufacturers
and continuing
- Ultra-Fast Programming Speed: Programs and verifies 64 Mb NOR Flash memory in
11.3 seconds.
- Concurrent & independent modules: 4 independent programming modules operating
concurrently for high speed programming.
- Built-in 144 universal pin drivers.
- CE and ROHS Compliant.
- SuperPro 501S N4 Cluster is composed of x4 units of our newest and fastest SuperPro 501S programmer w/ 4 pieces of 512 CF cards.
- Large device support: Supports 35,030 IC devices from 217 manufacturers
and continuing
- Fastest lowest cost Stand-Alone Programmer: With ARM7 MCU it gives ultra-fast programming experience.
- Two programmers in one, a double value: PC mode for engineering and Stand-alone mode for production. The programmer operates in either PC hosted mode or stand-alone mode.
- A CF (compact flash) card stores the project files.
- Built-in 48 universal pin drivers.
- CE and ROHS Compliant.
- High speed ARM9 CPU based hardware engine. Programming speed adjustable for complicated application environments brought by user target board, length of ISP cable etc..
- Supports ISP programming of devices with I2C, SPI, UART, BDM, MON, MW, JTAG, CAN, ICC, RS232 and any other serial ports.
- Supports ATE control.
- Supports 8 serial and 1 parallel programming devices.
- Dual modes: Stand-alone and PC-Host mode.
- DLL, API or Virtual Com communication command set available for third party application.
- USB 2.0 interface to PC for data communication and control.
- Software provides the features for multiple units to work concurrently controlled by USB HUB.
- Dynamic buffer function. Application examples include device S/N, MAC address, frequency or transducer calibration etc
- High speed ARM9 CPU based hardware engine. Programming speed adjustable for complicated application environments brought by user target board, length of ISP cable etc..
- Supports ISP programming of devices with I2C, SPI, CAN, UART, BDM, MW, JTAG, or any other serial port.
- Comes with ATE interface.
- Supports Linux O/S.
- Two operation modes: Stand-alone and PC-Host mode.
- DLL, API or Virtual Com communication command set available for third party application.
- USB 2.0 interface to PC for data communication and control.
- Over-current and ESD protection to protect your equipment.
- Lightest ever: Mechanical size: 137mm(L)x87mm(W)x47mm(H)
- High speed ARM9 CPU based hardware engine. Programming speed adjustable for complicated application environments brought by user target board.
- ISP cable accommodates I2C, SPI, UART, BDM, MON, MW, JTAG, CAN, ICC, RS232 interfaces.
- Cable driver circuit supports target voltage level of 1.5-5V and is also ESD protected.
- Volume production- Devices may be programmed after the board is fully assembled. One example is writing the serial number to an on-board serial device.
- Field application- Comes with portability, stand-alone mode, and an SD card. It is suitable for field tests, debugging and data acquisition.
- Supports Jam and Staple files from ACTEL and ALTERA; Direct C files from ACTEL.
- Dynamic buffer function. Application examples include: device serial number, MAC address, frequency or transducer calibration, etc.
- Internal Linux O/S.
- SuperBOT-I is an automated IC programming equipment, with high cost-effective, designed for manufacturing large-scale electronics. It uses Industrial Personal Computer (with control card inside), servo system and vision system mode to locate fast and accurately and finish chip capture, placement, programming, and packaging automatically instead of traditional manual operation.
- Throughput is up to 1400 UPH
- Internal programmer is 4 x SuperPro 5004GP
- Each module can burn chip independently
- Lower cost ever
- Support standart tray, tape, and tube
Xeltek's complete range of CX adapters for;
- PLCC,
- QFN, SOIC, SOP, SON, SOJ, TSSOP, SSOP, PSOP, TSOP,
- SDIP, QIP,
- BGA, PGA,
- QFP, PQFP.
- Erase quantity, 12 pieces (24 PIN)
- Mechanical timer can be set from 0 to 60 minutes.
- Protect users from UV exposure by equipped with automatic UV shut off switch when opening the device drawer.
- Erase time is approximately 15 minutes.
- Erase quantity, 64 pieces (24 PIN)
- Mechanical timer can be set from 0 to 60 minutes.
- Protect users from UV exposure by equipped with automatic UV shut off switch when opening the device drawer.
- Erase time is approximately 15 minutes.
